Bluetooth Low Energy and Bluetooth Mesh Modules, Bluetooth Xpress, SoCs and Software

Add Bluetooth^® into smart home, industrial, consumer electronics, beacons, fitness and medical applications with our Bluetooth SoCs, certified modules and software. Take advantage of the latest Bluetooth standards with our wireless stacks, easy to use development tools and various developer resources, including knowledge base articles, reference designs, application engineering support and mobile applications.

Bluetooth Low Energy and Bluetooth Mesh Select Columns

Select Columns

	Bluetooth Stack Support	RX 灵敏度	最大输出功率	TX 电流	RX Current (1M PHY)	CPU Core	GPIO	闪存	RAM	安全
FEATURED EFR32BG21 系列 2 SoC Bluetooth Low Energy EFR32BG21 Series 2 SoCs	Bluetooth 5 Bluetooth 5.1 Bluetooth Mesh	-97 (1 Mbit/s GFSK)	10, 20	10.4	8.7	ARM Cortex-M33		512, 768, 1024	64, 96	AES-256 ECC SHA-1 SHA-2
EFR32BG21 系列 2 模块 EFR32BG21 系列 2 模块	Bluetooth 5 BLE Bluetooth 5.1 Bluetooth Mesh	-97				ARM Cortex-M33	12, 20, 28	1024	96
EFR32BG13 系列 1 SoC Bluetooth Low Energy EFR32BG13 Series 1 SoCs	Bluetooth 5 Bluetooth 5.1 Bluetooth Mesh	-103.3-94.8 (1 Mbps 2 GFSK); -126.2 (600 bps GFSK 915 MHz), -94.8 (1 Mbps 2 GFSK)	0, 10, 19	8.5, 9.5	9.5	ARM Cortex-M4		512	64	AES-128 AES-256 ECC SHA-1 SHA-2
EFR32BG13 系列 1 模块 Bluetooth Low Energy EFR32BG13 Series 1 Modules	Bluetooth 5 BLE Bluetooth 5.1 Bluetooth Mesh	-94.1, -94.8				ARM Cortex-M4	25, 32	512	64
EFR32BG12 系列 1 SoC Bluetooth Low Energy EFR32BG12 Series 1 SoCs	Bluetooth 5 Bluetooth Mesh	-94.8 (1 Mbps 2 GFSK), -94.8 (1 Mbps 2 GFSK); -126.2 (600 bps GFSK 915 MHz)	0, 10, 19	9.5	10	ARM Cortex-M4		512, 1024	64, 128, 256	AES-128 AES-256 ECC SHA-1 SHA-2
EFR32BG1 系列 1 SoC Bluetooth Low Energy EFR32BG1 Series 1 SoCs	蓝牙 5	-92.5 (1 Mbps 2 GFSK), -92.5 (1 Mbps 2 GFSK); -126.4 (600 bps GFSK 915 MHz)	3.5, 10.5, 19.5, 20	8.2	8.7	ARM Cortex-M4		256	32	AES-128 AES-256 ECC SHA-1 SHA-2
EFR32BG1 系列 1 模块 Bluetooth Low Energy EFR32BG1 Series 1 Modules	BLE Bluetooth 5.1	-90, -92				ARM Cortex-M4		256	32
无线 Xpress BGX13 Bluetooth Low Energy Wireless Xpress BGX13	Bluetooth 5 BLE Bluetooth Mesh	-94.1, -94.8	8				8
Bluegiga 传统模块 Bluetooth Low Energy Bluegiga Legacy Modules	BLE	-92, -93, -98				8051	1	128, 256	8

Bluetooth Classic Select Columns

Select Columns

	蓝牙BR/EDR	RX 灵敏度	TX Current @ 0 dBm	范围	尺寸 (mm)
Bluegiga 传统模块 Bluetooth Classic Bluegiga Legacy Modules		-86, -89, -90, -96	+12 (BR/EDR) +8 (BLE), +17, +18, +3, +6.5, +8	100+ 米, 200-400 米 LoS 范围, 30 米视线, 350 米视线, 500+ 米视线, 长达 200 米	11.0 x 13.9 x 2.2, 13.05 x 9.30 x 2.1, 25.5 x 14.0 x 2.4, 35.55 x 14.50 x 3.65, 35.75 x 14.50 x 2.6
